Finding Icebergs in Language-Model Workflow: Diagnosing Latent Structural Fragility with Stochastic Semantic Evidence Graphs

Abstract

AI-workflow governance cannot be reduced to checking the final answer: an apparently safe answer may rest on a fragile evidence path that ordinary evaluation cannot see, localize or govern. We call this hidden fragility a"structural iceberg": hallucinations and unsupported claims may form its visible tip, while consequential weakness remains submerged. Stochastic semantic evidence graphs (SSEGs) expose these icebergs by preserving workflow channels, propagating local uncertainty and identifying the hidden paths on which an apparently safe output depends. ALCE and RAGTruth show that visible failures at the tip -unsupported citations and hallucinated spans -rest on distinct submerged weaknesses and therefore require different interventions. Across retrieval, tool-use and controlled stress tests, SSEG localizes those weaknesses, supports targeted repair, produces no false automatic passes in 35,000 known-truth cases and reduces ToolSandbox review by 28.8% across 96 executions from two agent models. The same structural view carries into end-to-end governance: in a separately sealed 1,200-case FinGovBench study, adding SSEG to GPT-OSS-20B reduces unsafe releases from 452/660 to 8/660 while releasing all 540 safe cases and correctly distinguishing 592/600 matched workflow pairs. An unchanged-gate transfer to Qwen3-8B releases all 540 safe cases and none of 660 unsafe cases, whereas flat-UQ releases 520 unsafe cases. SSEG therefore moves governance below surface-level output checking, turning hidden evidence dependencies into auditable, path-specific decisions about intervention, revalidation and release.
